Product benefits
- Good glare reduction (UGR < 19) and cut off angle up to 30° for comfortable indoor lighting
- Easy and quick installation thanks to connector box with 5-pole toolless terminal
- Low flicker light
- Suitable for use in dusty and damp locations thanks to high IP rating
Areas of application
- Suitable for office applications, especially for computer screen workplaces
- Direct replacement for luminaires with compact fluorescent lamps
- Entrances / Hallways
- Bathrooms, kitchens and sheltered outdoor areas
- General illumination
Product features
- Housing material: Aluminum mirror-finished reflector
- Type of protection: IP54 (room side) / IP20 (back side)
- Connector box with push wire terminal for tool-free connection
- Through-wiring possible
- Luminaire versions with IoT-ready DALI-2 driver or IoT Zigbee 3.0 technology available
Technical data
Electrical data
Nominal wattage | 21.00 W |
Nominal voltage | 220…240 V |
Mains frequency | 50…60 Hz |
Nominal current | 120 mA |
Inrush current | 30 A |
Inrush current time Th50 | 200 µs |
Max. number of luminaires per miniature circuit breaker B16 | 120 |
Max. number of luminaires per miniature circuit breaker C10 | 80 |
Max. number of luminaires per miniature circuit breaker C16 | 120 |
Power factor λ | ≥0.90 |
Total harmonic distortion | < 20 % |
Protection class | II |
Operating mode | External LED driver |
Photometrical data
Luminous flux | 2520 lm |
Luminous efficacy | 120 lm/W |
Color temperature | 4000 K |
Light color (designation) | Cool White |
Color rendering index Ra | ≥80 |
Standard deviation of color matching | ≤5 sdcm |
Luminous intensity | - |
Low flicker | Yes |
Flickering metric (Pst LM) | - |
Stroboscope effect metric (SVM) | - |
Photobiological safety group acc. to EN62778 | RG1 |
Photobiological safety group acc. to EN62471 | RG0 |
Beam angle | 65 ° |
UGR | < 19 |
Dimensions & Weight
Diameter | 220.00 mm |
Height | 82.00 mm |
Product weight | 900.00 g |
Materials & Colors
Product color | White |
Housing color | White |
Body material | Aluminum |
Cover material | Polycarbonate (PC) |
Light emitting surface material | Polycarbonate (PC) |
Glow Wire Test according to IEC 60695-2-12 | 650 °C |
Mercury content | 0.0 mg |
Application & Mounting
Ambient temperature range | -20…+45 °C |
Temperature range at storage | -40…+70 °C |
Type of connection | Screwless terminal |
Type of protection | IP54/IP20 |
Protection class IK (shock resistance) | IK03 |
Dimmable | No |
Mounting type | Recessed |
Mounting location | Ceiling |
Application environment | Indoor |
Mounting diameter | 195,0 mm |
Mounting depth | 120 mm |
With light source | Yes |
Replaceable light source | No |
Lifespan
Lifespan L70/B50 at 25 °C | 70000 h 1) |
Lifespan L80/B10 at 25 °C | 60000 h 1) |
Lifespan L90/B10 at 25 °C | 40000 h |
Number of switching cycles | 100000 |
1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)
Control gear
Output current | 700 mA |
ECG - Output ripple current | < 10 % |
ECG - Length | 114.0 mm |
ECG - Width | 45 mm |
ECG - Height | 28 mm |
Recommended control gear | OSRAM OTI DALI 50/220-240/1A4 NFC |
Certificates & Standards
Standards | CE, CB, ENEC, TÜV SÜD, EAC |
Luminaire with limited surface temperature, "D sign" | No |
Ball shot safe | No |
Replaceable light source (EPREL) | Not replaceable |
Additional product data
Number of illuminants | Not relevant |
PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS
Quantity of precious metals | Contains at least 10 mg |
Quantity of rare earths | Contains at least 1 mg |
Виж още LED Луни Ledvance
Виж всички LED Луни в категорията
Технически характеристики
Тип: | Луна кръг |
---|---|
Влагозащитеност: | IP54 (Външна употреба) |
Мощност: | 21 W |
Напрежение: | 240 V |
Светлинен поток: | 2520 lm |
Цветна температура: | Неутрално бяла |
Монтажен размер: | 220x82mm |
Особеност: | Няма |
