Процесор Intel Xeon E5-2680 v4, четиринадесетядрен (2.40/3.30 GHz, 35MB, 2011-3), Tray

Intel Xeon E5-2680 v4 Tray


Essentials:
Product Collection:
Intel® Xeon® Processor E5 v4 Family

Code Name:
Products formerly Broadwell

Vertical Segment:
Server

Processor Number:
E5-2680V4

Status:
Launched

Launch Date:
Q1'16

Lithography:
14 nm

Performance:
# of Cores:
14

# of Threads:
28

Processor Base Frequency:
2.40 GHz

Max Turbo Frequency:
3.30 GHz

Cache:
35 MB SmartCache

Bus Speed:
9.6 GT/s QPI

# of QPI Links:
2

TDP:
120 W

VID Voltage Range:
0

Supplemental Information:
Embedded Options Available:
Yes

Conflict Free:
Yes

Memory Specifications:
Max Memory Size (dependent on memory type)
1.54 TB

Memory Types:
DDR4 1600/1866/2133/2400

Max # of Memory Channels:
4

Max Memory Bandwidth:
76.8 GB/s

Physical Address Extensions:
46-bit

ECC Memory Supported ‡:
Yes

Graphics Specifications:
Processor Graphics ‡:
None

Expansion Options:
Scalability:
2S

PCI Express Revision:
3.0

PCI Express Configurations ‡:
x4, x8, x16

Max # of PCI Express Lanes:
40

Package Specifications:
Sockets Supported:
FCLGA2011-3

Max CPU Configuration:
2

TCASE:
86°C

Package Size:
45mm x 52.5mm

Advanced Technologies:
Intel® Turbo Boost Technology ‡:
2.0

Intel® vPro™ Technology ‡:
Yes

Intel® Hyper-Threading Technology ‡:
Yes

Intel® Virtualization Technology (VT-x) ‡:
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡:
Yes

Intel® VT-x with Extended Page Tables (EPT) ‡:
Yes

Intel® TSX-NI:
Yes

Intel® 64 ‡:
Yes

Instruction Set:
64-bit

Instruction Set Extensions:
AVX 2.0

Idle States:
Yes

Enhanced Intel SpeedStep® Technology:
Yes

Intel® Demand Based Switching:
Yes

Thermal Monitoring Technologies:
Yes

Intel® Flex Memory Access:
No

Intel® Identity Protection Technology ‡:
No

Intel® Data Protection Technology:
Intel® AES New Instructions:
Yes

Secure Key:
Yes

Intel® Platform Protection Technology:
OS Guard:
Yes

Trusted Execution Technology ‡:
Yes

Execute Disable Bit ‡:
Yes
