Intel Xeon E5-2643 v4
Essentials:
Product Collection:
Intel® Xeon® Processor E5 v4 Family
Code Name:
Products formerly Broadwell
Vertical Segment:
Server
Processor Number:
E5-2643V4
Status:
Launched
Launch Date:
Q1'16
Lithography:
14 nm
Performance:
# of Cores
6
# of Threads:
12
Processor Base Frequency:
3.40 GHz
Max Turbo Frequency:
3.70 GHz
Cache:
20 MB SmartCache
Bus Speed:
9.6 GT/s QPI
# of QPI Links:
2
TDP:
135 W
Memory Specifications:
Max Memory Size (dependent on memory type):
1.54 TB
Memory Types:
DDR4 1600/1866/2133/2400
Max # of Memory Channels:
4
Max Memory Bandwidth:
76.8 GB/s
Physical Address Extensions:
46-bit
ECC Memory Supported ‡:
Yes
Expansion Options:
Scalability
2S
PCI Express Revision:
3.0
PCI Express Configurations ‡:
x4, x8, x16
Max # of PCI Express Lanes:
40
Package Specifications:
Sockets Supported:
FCLGA2011-3
Max CPU Configuration:
2
TCASE:
75°C
Package Size:
45mm x 52.5mm
Advanced Technologies:
Intel® Turbo Boost Technology ‡
2.0
Intel® vPro™ Technology ‡:
Yes
Intel® Hyper-Threading Technology ‡:
Yes
Intel® Virtualization Technology (VT-x) ‡:
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡:
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡:
Yes
Intel® TSX-NI:
Yes
Intel® 64 ‡:
Yes
Instruction Set:
64-bit
Instruction Set Extensions:
AVX 2.0
Idle States:
Yes
Enhanced Intel SpeedStep® Technology:
Yes
Intel® Demand Based Switching:
Yes
Thermal Monitoring Technologies:
Yes
Intel® Data Protection Technology:
Intel® AES New Instructions:
Yes
Secure Key:
Yes
Intel® Platform Protection Technology:
OS Guard:
Yes
Trusted Execution Technology ‡:
Yes
Execute Disable Bit ‡:
Yes
Виж още Сървъри Процесори Intel
Виж всички Сървъри Процесори в категорията
Essentials:
Product Collection:
Intel® Xeon® Processor E5 v4 Family
Code Name:
Products formerly Broadwell
Vertical Segment:
Server
Processor Number:
E5-2643V4
Status:
Launched
Launch Date:
Q1'16
Lithography:
14 nm
Performance:
# of Cores
6
# of Threads:
12
Processor Base Frequency:
3.40 GHz
Max Turbo Frequency:
3.70 GHz
Cache:
20 MB SmartCache
Bus Speed:
9.6 GT/s QPI
# of QPI Links:
2
TDP:
135 W
Memory Specifications:
Max Memory Size (dependent on memory type):
1.54 TB
Memory Types:
DDR4 1600/1866/2133/2400
Max # of Memory Channels:
4
Max Memory Bandwidth:
76.8 GB/s
Physical Address Extensions:
46-bit
ECC Memory Supported ‡:
Yes
Expansion Options:
Scalability
2S
PCI Express Revision:
3.0
PCI Express Configurations ‡:
x4, x8, x16
Max # of PCI Express Lanes:
40
Package Specifications:
Sockets Supported:
FCLGA2011-3
Max CPU Configuration:
2
TCASE:
75°C
Package Size:
45mm x 52.5mm
Advanced Technologies:
Intel® Turbo Boost Technology ‡
2.0
Intel® vPro™ Technology ‡:
Yes
Intel® Hyper-Threading Technology ‡:
Yes
Intel® Virtualization Technology (VT-x) ‡:
Yes
Intel® Virtualization Technology for Directed I/O (VT-d) ‡:
Yes
Intel® VT-x with Extended Page Tables (EPT) ‡:
Yes
Intel® TSX-NI:
Yes
Intel® 64 ‡:
Yes
Instruction Set:
64-bit
Instruction Set Extensions:
AVX 2.0
Idle States:
Yes
Enhanced Intel SpeedStep® Technology:
Yes
Intel® Demand Based Switching:
Yes
Thermal Monitoring Technologies:
Yes
Intel® Data Protection Technology:
Intel® AES New Instructions:
Yes
Secure Key:
Yes
Intel® Platform Protection Technology:
OS Guard:
Yes
Trusted Execution Technology ‡:
Yes
Execute Disable Bit ‡:
Yes
Виж още Сървъри Процесори Intel
Виж всички Сървъри Процесори в категорията
Технически характеристики
Процесор сокет: | LGA2011-3 |
---|
