Процесор Intel Xeon E5-1630 v4, четириядрен (3.70/4.00 GHz, 10MB, 2011-3)Tray

Intel Xeon E5-1630 v4
CM8066002395300SR2PF

Essentials:
Product Collection:
Intel® Xeon® Processor E5 v4 Family

Code Name:
Products formerly Broadwell

Vertical Segment:
Server

Processor Number:
E5-1630V4

Status:
Launched

Launch Date:
Q2'16

Lithography:
14 nm

Performance:
# of Cores
4

# of Threads:
8

Processor Base Frequency:
3.70 GHz

Max Turbo Frequency:
4.00 GHz

Cache:
10 MB

Bus Speed:
0 GT/s QPI

# of QPI Links:
0

TDP:
140 W

Memory Specifications:
Max Memory Size (dependent on memory type):
1.54 TB

Memory Types:
DDR4 1600/1866/2133/2400

Max # of Memory Channels:
4

Max Memory Bandwidth:
76.8 GB/s

Physical Address Extensions:
46-bit

ECC Memory Supported ‡:
Yes

Expansion Options:
Scalability:
1S Only

PCI Express Revision:
3.0

PCI Express Configurations ‡:
x4, x8, x16

Max # of PCI Express Lanes:
40

Package Specifications:
Sockets Supported
FCLGA2011-3

Max CPU Configuration:
1

TCASE:
69°C

Package Size:
45mm x 52.5mm


Advanced Technologies:
Intel® Turbo Boost Max Technology 3.0 ‡:
Yes

Intel® Turbo Boost Technology ‡:
2.0

Intel® vPro™ Technology ‡:
Yes

Intel® Hyper-Threading Technology ‡:
Yes

Intel® Virtualization Technology (VT-x) ‡:
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡:
Yes

Intel® VT-x with Extended Page Tables (EPT) ‡:
Yes

Intel® TSX-NI:
Yes

Intel® 64 ‡:
Yes

Instruction Set:
64-bit

Instruction Set Extensions:
AVX 2.0

Idle States:
Yes

Enhanced Intel SpeedStep® Technology:
Yes

Intel® Demand Based Switching:
Yes

Thermal Monitoring Technologies:
Yes

Intel® Flex Memory Access:
No

Intel® Identity Protection Technology ‡:
Yes

Intel® Data Protection Technology
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® Platform Protection Technology
OS Guard
Yes
Trusted Execution Technology ‡
Yes
Execute Disable Bit ‡
Yes
