Процесор Intel Xeon E3-1270 v6, четириядрен (3.80/4.20 GHz, 8MB, LGA1151), Tray

Intel CPU Server Quad-Core Xeon E3-1270V6 (3.8 GHz, 8M Cache, LGA1151) tray

Essentials
Product Collection:
Intel® Xeon® Processor E3 v6 Family

Code Name:
Products formerly Kaby Lake

Vertical Segment:
Server

Processor Number:
E3-1270V6

Status:
Launched

Launch Date:
Q1'17

Lithography:
14 nm

Performance:
# of Cores
4

# of Threads:
8

Processor Base Frequency:
3.80 GHz

Max Turbo Frequency:
4.20 GHz

Cache:
8 MB

Bus Speed:
8 GT/s DMI3

TDP:
72 W

VID Voltage Range:
0.55V-1.52V

Memory Specifications:
Max Memory Size (dependent on memory type)
64 GB

Memory Types:
DDR4-2400, DDR3L-1866

Max # of Memory Channels:
2

Max Memory Bandwidth:
37.5 GB/s

ECC Memory Supported ‡:
Yes

Expansion Options:
Scalability
1S Only

PCI Express Revision:
3.0

PCI Express Configurations ‡:
1x16, 2x8. 1x8+2x4

Max # of PCI Express Lanes:
16

Package Specifications:
Sockets Supported
FCLGA1151

Max CPU Configuration:
1

Package Size:
37.5mm x 37.5mm

Advanced Technologies:
Intel® Optane™ Memory Supported ‡
Yes

Intel® Turbo Boost Technology ‡:
2.0

Intel® vPro™ Technology ‡:
Yes

Intel® Hyper-Threading Technology ‡:
Yes

Intel® Virtualization Technology (VT-x) ‡:
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡:
Yes

Intel® VT-x with Extended Page Tables (EPT) ‡:
Yes

Intel® TSX-NI:
Yes

Intel® 64 ‡:
Yes

Instruction Set:
64-bit

Instruction Set Extensions:
SSE4.1/4.2, AVX 2.0

Idle States:
Yes

Enhanced Intel SpeedStep® Technology:
Yes

Thermal Monitoring Technologies:
Yes

Intel® Data Protection Technology:
Intel® AES New Instructions
Yes

Secure Key:
Yes

Intel® Software Guard Extensions (Intel® SGX):
Yes

Intel® Memory Protection Extensions (Intel® MPX):
Yes

Intel® Platform Protection Technology:
OS Guard
Yes

Intel® Trusted Execution Technology ‡:
Yes

Execute Disable Bit ‡:
Yes

Intel® Device Protection Technology with Boot Guard:
Yes
