Процесор Intel Xeon E3-1245 v5, четириядрен (3.50/3.90 GHz, 8MB, LGA1151)Tray

Intel Xeon E3-1245 v5

Essentials:
Export specifications:
Product Collection:
Intel® Xeon® Processor E3 v5 Family

Code Name
Products formerly Skylake

Vertical Segment
Server

Processor Number
E3-1245V5

Status
Launched

Launch Date
Q4'15

Lithography
14 nm

Performance:
# of Cores
4

# of Threads:
8

Processor Base Frequency
3.50 GHz

Max Turbo Frequency
3.90 GHz

Cache
8 MB SmartCache

Bus Speed
8 GT/s DMI3

TDP
80 W

VID Voltage Range
0.55V-1.52V

Memory Specifications:
Max Memory Size (dependent on memory type)
64 GB

Memory Types
DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V

Max # of Memory Channels
2

Max Memory Bandwidth
34.1 GB/s

ECC Memory Supported ‡
Yes

Graphics Specifications:
Processor Graphics ‡
Intel® HD Graphics P530

Graphics Base Frequency
400.00 MHz

Graphics Max Dynamic Frequency
1.15 GHz

Graphics Video Max Memory
1.7 GB

Graphics Output
eDP/DP/HDMI/DVI

4K Support
Yes, at 60Hz

Max Resolution (HDMI 1.4)‡
4096x2304@24Hz

Max Resolution (DP)‡
4096x2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)‡
4096x2304@60Hz

Max Resolution (VGA)‡
N/A

DirectX* Support
12

OpenGL* Support
4.4

Intel® Quick Sync Video
Yes

Intel® InTru™ 3D Technology
Yes

Intel® Clear Video HD Technology
Yes

Intel® Clear Video Technology
Yes

# of Displays Supported ‡
3

Device ID
0x191D

Expansion Options
Scalability
1S Only

PCI Express Revision
3.0

PCI Express Configurations ‡
1x16, 2x8, 1x8+2x4

Max # of PCI Express Lanes
16

Package Specifications
Sockets Supported
FCLGA1151

Max CPU Configuration
1

Package Size
37.5mm x 37.5mm

Advanced Technologies
Intel® Turbo Boost Technology ‡
2.0

Intel® vPro Technology ‡
Yes

Intel® Hyper-Threading Technology ‡
Yes

Intel® Virtualization Technology (VT-x) ‡
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes

Intel® VT-x with Extended Page Tables (EPT) ‡
Yes

Intel® TSX-NI
Yes

Intel® 64 ‡
Yes

Instruction Set
64-bit

Instruction Set Extensions
SSE4.1/4.2, AVX 2.0

Idle States
Yes

Enhanced Intel SpeedStep® Technology
Yes

Thermal Monitoring Technologies
Yes

Intel® Data Protection Technology
Intel® AES New Instructions
Yes

Secure Key
Yes

Intel® Software Guard Extensions (Intel® SGX)
Yes

Intel® Memory Protection Extensions (Intel® MPX)
Yes

Intel® Platform Protection Technology
OS Guard
Yes

Trusted Execution Technology ‡
Yes

Execute Disable Bit ‡
Yes

Intel® Device Protection Technology with Boot Guard
Yes
