PB6UD
Eaton Protection Box 6 USB DIN
Eaton Protection Box 6 DIN, 10A, Input: Schuko, Output: (6) Schuko, (2) USB Charging Ports
General specifications
| Product Length/Depth | 245 mm |
| Product Height | 110 mm |
| Product Width | 47.5 mm |
| Product Weight | 0.612 kg |
| Compliances | EAC CE Marked |
| Certifications | IEC/EN 60884-1 IEC/EN 61643-11 |
| Model Code | Eaton Protection Box 6 USB DIN |
More additional specifications
| Amperage Rating | 10A |
| Indicator type | Color LED |
| Material | Plastic |
| Special features | High end multi outlets surge protection device implementing 6 Schuko (DIN) sockets, IEC 61643-11 compliant, 2 USB ports, including connected equipment warranty |
| Type | Surge Suppressor |
Outlet surge suppressor specifications
| Angle of rotated central insert | Other |
| Circuit breaker | Yes |
| Color | Black/white |
| Core cross section | 0 mm² |
| Degree of Protection | IP20 |
| Halogen Free | No |
| Housing shape | Rectangular |
| Input connection | Protective contact (SCHUKO) |
| Internet/tel line protection | No |
| Interrupt rating | 10 AIC |
| Material | Plastic |
| Material quality | Other |
| NEMA designation | None |
| Nominal frequency | 50-60 Hz |
| Number of cold device socket outlets | 3 |
| Number of NEMA-Outlets | 0 |
| Number of outlets | 6 |
| Number of outputs (other) | 3 |
| Number of socket outlets with protective contact | 6 |
| Number of USB connections | 2 |
| Operating temperature - max | 40 °C |
| Operating temperature - min | 0 °C |
| Operating voltage | 220-250 V |
| Power cord length | 1.5 m |
| RAL-number | 9003 |
| Residual current circuit breaker | No |
| Fitted with: | LED indication Over voltage protection Fuse On/Off switch |
| Surface finish | Matt/Matte |
| Surface protection | Other |
| Surge rating | 1500 V |
| Switchable | Yes |
| Transparent | No |
Surge protective device specifications
| Mounting Method | Portable 35 mm DIN rail |
| Phase | Single-phase |
| Surge current | 3000A |
