Кабел Delock 86037, от USB-C(м) към DisplayPort(м), 0.5m, черен, 8K@60Hz

This DP 8K certified USB-C™ to DisplayPort cable by Delock enables the connection between different devices with USB Type-C™ and DisplayPort connectors.

Versatile applications
The bidirectional cable works in both signal directions and therefore offers a variety of possible applications. It can be used, for example, to connect a monitor or TV with DisplayPort socket to a laptop or smartphone with USB Type-C™ port. Alternatively it is possible to connect a USB Type-C™ monitor to a device with DisplayPort output.

8K Ultra HD resolution and HDR support
By supporting a maximum bandwidth of 32.4 Gbps, content up to 8K Ultra HD (7680 x 4320 @ 60 Hz) resolution can be displayed.
Due to the HDR support colours are realistically displayed with impressive depth, brightness and contrast are optimally reproduced.

Technical details

• Connectors:
  1 x USB Type-C™ male >
  1 x DisplayPort male

• Chipset: Chrontel CH7213

• DisplayPort 1.4 specification

• Downwards compatible to DisplayPort 1.3, 1.2 and 1.1

• DisplayPort® DP 8K certified cable

• Cable gauge: 32 AWG

• Cable diameter: ca. 4.8 mm

• Copper conductor

• Triple shielded cable

• Contacts gold-plated

• Transmission of audio and video signals

• Data transfer rate up to 32.4 Gbps

• Resolution up to:
  Display with DSC support:
  7680 x 4320 @ 60 Hz
  5120 x 2880 @ 120 Hz
  3840 x 2160 @ 240 Hz
  Display without DSC support:
  7680 x 4320 @ 30 Hz
  5120 x 2880 @ 60 Hz
  3840 x 2160 @ 120 Hz
  (depending on the system and the connected hardware)

• Supports Display Stream Compression 1.2 (DSC)

• Supports HDR

• Supports HDCPHigh-bandwidth Digital Content Protection is an encryption system that is used for the DVI, HDMI and DisplayPort interfaces for protected transmission of audio and video data. 1.4 and 2.2

• Supports HBR3 (8.1 Gbps) data rate

• Up to 32 audio channels for speakers

• Up to 1536 kHz audio sampling rate

• Supports colour sampling in 4:4:4, 4:2:2 and 4:2:0 format

• Plug & Play

• Colour: black

• Length incl. connectors: ca. 0.5 m

System requirements

• Android 8.0 or above

• Chrome OS 71.0 or above

• iOS 12.1.4 or above

• Mac OS 10.14.2 or above

• Windows 7/7-64/8.1/8.1-64/10/10-64

• PC or laptop with a free USB Type-C™ port and DisplayPort alternate mode or

• PC or laptop with a free ThunderboltThunderbolt is a versatile interface that combines the transmission of power, data, image and sound to peripheral devices such as monitors and hard drives in a single cable. From Thunderbolt 3 onwards, a USB-C connector is used, making it compatible with USB.™ 3 port

• A free DisplayPort interface
