Technical Specifications
Model: DH-PFM920I-5EUN
Conductor
Material: OFC(oxygen free copper)
Compositio: 1/0.45
Wire gauge: 0.45*4P±0.005mm
Insulation
Material: HDPE
Min. average thickness: 0.2mm
Diameter: 0.83mm±0.03mm
Lay of twisted conductors: 140mm
Jacket
Material: PVC
Min. average thickness: 0.5mm±0.05mm
Diameter: 4.7mm
Color: Orange and white are optional
Length: 305m (1000.66ft)
Max. DC resistance of single conductor: 12 Ω/100m
Max. unbalance rate of line pairs’ direct current resistance: 12%
Min. insulation resistance: 5000MΩ·km
Max. mutual capacitance 5.6NF/100m
Max. attenuation: 22(dB/100m, 100MHz)
General
N.W.: 7.8kg
Packaging dimension: 360mmx360mmx220mm
Weight (with packaging): 8.6kg
Виж още Мрежови кабели медни Dahua
Виж всички Мрежови кабели медни в категорията
Model: DH-PFM920I-5EUN
Conductor
Material: OFC(oxygen free copper)
Compositio: 1/0.45
Wire gauge: 0.45*4P±0.005mm
Insulation
Material: HDPE
Min. average thickness: 0.2mm
Diameter: 0.83mm±0.03mm
Lay of twisted conductors: 140mm
Jacket
Material: PVC
Min. average thickness: 0.5mm±0.05mm
Diameter: 4.7mm
Color: Orange and white are optional
Length: 305m (1000.66ft)
Max. DC resistance of single conductor: 12 Ω/100m
Max. unbalance rate of line pairs’ direct current resistance: 12%
Min. insulation resistance: 5000MΩ·km
Max. mutual capacitance 5.6NF/100m
Max. attenuation: 22(dB/100m, 100MHz)
General
N.W.: 7.8kg
Packaging dimension: 360mmx360mmx220mm
Weight (with packaging): 8.6kg
Виж още Мрежови кабели медни Dahua
Виж всички Мрежови кабели медни в категорията
Технически характеристики
| Вид: | Ролка |
|---|---|
| Тип: | UTP |
| Категория: | Cat 5e |
| Дължина: | 305 m |
