Видеорекордер NVR, D-Link 2-Bay Professional Network Video Recorder DNR-326, 9 канала live view/recording, 4 канала playback, 802.3/u/z

Standards
IEEE802.3/u/z
Auto MDI/MDI-X
SATA I/II

HDD
HDD reformat
RAID 0, 1
JBOD

Security
Cover lock
Security slot for Kensington locks

Memory
Flash ROM: 32 MB
RAM: 128 MB DDR II

Interfaces
1x Gigabit LAN port
1x USB port for USP status update

Power
DC 12V / 4A
Max. power consumption: 25.20 W
Stand-by power consumption: 0.234 W

Temperature
Operation: 0 to 55 °C
Storage: -20 to 70 °C

Humidity
5% to 90% (non-condensing)

Dimensions (W x D x H)
115 x 146.4 x 178.5 mm

Weight
0.875 Kg

Certifications
CE
FCC
RoHS

Software

Operating system
Linux

Supported Cameras
Supports all D-Link network cameras.
Includes support for auto-discovery and megapixel resolution
Supports known-brand network cameras including D-Link, Axis, Panasonic, Sony, Mobotix, Arecont Vision, IQinVision, Cisco, and Acti

Recording Performance
Max. capacity (NVR mode only):
H.264 1080P (bitrate): 90 Mbps
H.264 720P (bitrate): 90 Mbps
MJPEG 1080P (frame rate): 90 fps
MJPEG 720P (frame rate): 192 fps
Max. capacity (NVR+File Server mode):
H.264 1080P (bitrate): 68 Mbps
H.264 720P (bitrate): 68 Mbps
MJPEG 1080P (frame rate): 70 fps
MJPEG 720P (frame rate): 150 fps
Camera Search
UPnP

Audio & Video Recording
Synchronized audio & video recording

Compression Format
H.264, MPEG-4, M-JPEG (for supported cameras)

Video Setting
Resolution, quality, frame rate, enable audio, go to camera interface

Recording Type
Recording by schedule, manual and event (DI trigger, motion detection from camera)

Remote Live View
Supported via IE remote live viewer
Maximum 9 simultaneous channels

Remote Live View Control
Live view, preset/go, patrol, focus, PTZ functions, snapshot, full screen, digital zoom

Remote Playback Control
Playback with normal, fast forward/rewind and step forward/rewind
Smart Search intelligent detection function: General Motion, Missing Object, Foreign Object, Camera Occlusion, Lose Focus

Remote Playback
Supported via IE and NVR client
Playback system with timeline GUI, search by event, area, cameras, date, and time
IE & NVR client support four channel simultaneous playback

Overwrite Recording
Auto recycling when disk storage is full

File Export
Export videos to AVI or ASF file
Export images to BMP or JPG file

User Account
Additional accounts can be created to allow user access to the system and specify authorization for camera channels, PTZ, etc.

DDNS
D-Link DDNS server support

Reset modes
Reset firmware GUI button
HW reset button (hold for 5 seconds)

System Time
Set the system time (D-Link NTP, input time, sync with computer, Daylight Saving Time)

Remote Backup
Remote software can backup raw data to redundant storage
Backup recorded data to remote FTP site by daily schedule

Status
Camera status
System status

Network Service Protocols
IPV4, ARP, TCP, UDP, ICMP
DHCP Server
DHCP Client
NTP Client (D-Link)
DNS Client
DDNS Client (D-Link)
SMTP Client
HTTP Server
PPPoE
UPnP
IP filtering
Samba Server

User Interface
HTTP Web browser
Internet Explorer 7 or later
NVR Search utility
Multiple Language GUI
