Конферентна система Cisco Room Kit, 4K/UHD 120° камера, Stereo Speaker, Wi-Fi, Bluetooth, LAN, USB-C

Cisco Room Kit CS-KIT-K9

Optional hardware components
● Cisco Table Microphone 20
● Microphone extension cable
● HDMI second monitor cable 1.5 m/4.9 ft.
● HDMI presentation cable 8 m/26.2 ft.

Bandwidth
● Up to 6 Mbps point-to-point

Minimum bandwidth for
resolution/frame rate
H.264:
● 720p30 from 768 kbps
● 720p60 from 1152 kbps
● 1080p30 from 1472 kbps
● 1080p60 from 2560 kbps

Firewall traversal technology
● Cisco Expressway™
● H.460.18, H.460.19 firewall traversal

Video standards
● H.264, H.265

Video inputs
● One HDMI input supports formats up to maximum 4K (3840 x 2160) at 30 fps including HD1080p60
● Consumer Electronics Control (CEC) 2.0

Video outputs
● Two HDMI outputs support formats up to 3840 x 2160p60 (4Kp60)
● Live video resolutions (encode and decode) up to 1920 x 1080p30 and p60 (HD1080p)
● Consumer Electronics Control (CEC) 2.0

Audio standards
● G.711, G.722, G.722.1, G.729, AAC-LD, and Opus

Audio features
● High-quality 20 kHz audio
● Prepared for subwoofer (line out)
● Prepared for inductive loop (line out)
● Automatic Gain Control (AGC)
● Automatic noise reduction
● Active lip synchronization

Audio inputs
● Two microphones, 4-pin mini-jack
● One audio in from HDMI
● Internal microphone

Audio outputs (external)
● 1 line out mini-jack (stereo)

Speakers (integrated)
● High-quality speakers: five speakers in balanced configuration
● Frequency response 70 Hz to 20 kHz
● Amplifier power: 24W
● Max output level SPL 86 dB

Speaker tracking
● 6-element microphone array for accurate speaker tracking

Dual stream
● H.239 (H.323) dual stream
● Binary Floor Control Protocol (BFCP) (SIP) dual stream
● Supports resolutions up to 3840 x 2160p5

Wireless sharing
● Cisco Spark client (up to 3840 x 2160p5)
● Cisco Intelligent Proximity client (up to 1920 x 1080p5)

MultiSite features
(embedded multipoint)
(optional upgrade)
● Adaptive SIP/H.323 MultiSite:
◦ 3-way resolution up to 1080p30 + content up to 4Kp5
◦ 4-way resolution up to 720p30 + content up to 4Kp5
● Full individual audio and video transcoding
● H.323/SIP/VoIP in the same conference
● Support for presentation (H.239/BFCP) from any participant at resolutions up to 3840 x 2160p5
● Best Impression (automatic continuous presence layouts)
● Encryption and dual stream from any site

Embedded encryption
● H.323 and SIP point-to-point
● Standards-based: H.235 v3 and Advanced Encryption Standard (AES)
● Automatic key generation and exchange


IP network features
● DNS lookup for service configuration
● Differentiated services (quality of service [QoS])
● IP-adaptive bandwidth management (including flow control)
● Automatic gatekeeper discovery
● Dynamic playout and lip-sync buffering
● H.245 dual-tone multifrequency (DTMF) tones in H.323
● RFC 4733 DTMF tones in SIP
● Date and time support using Network Time Protocol (NTP)
● Media adaptation and resilience
● Uniform resource identifier (URI) dialing
● Dynamic Host Configuration Protocol (DHCP)
● 802.1X network authentication
● 802.1Q Virtual LAN
● 802.1p (QoS and class of service [CoS])

IPv6 network support
● Single call stack support for both H.323 and SIP
● Dual-stack IPv4 and IPv6 for DHCP, SSH, HTTP, HTTPS, DNS, DiffServ
● Support for both static and automatic IP configuration (stateless address auto configuration)


Security features
● Management using HTTPS and SSH
● IP administration password
● Menu administration password
● Disable IP services
● Network settings protection

Network interfaces
● One Ethernet (RJ-45) 10/100/1000 for LAN
● One Ethernet (RJ-45) for Cisco Touch 10 direct pairing
● Wi-Fi 802.11a/b/g/n/ac 2.4 GHz/5 GHz, 2x2 MIMO
● Bluetooth 4.0 LE

Other interfaces
● USB 2.0 port, USB, factory reset pinhole

Power
● 100 to 240 VAC, 50/60 Hz, 12V DC input
● Average 20W, peak 70W

Camera Overview
● 5K UltraHD camera
● Supports up to 60 fps (max 30 fps with speaker tracking and best overview enabled)
● 15.1 MP image sensor (5184 x 2916 pixels)
● 1/1.7 CMOS
● 3x zoom
● f/2.0 aperture
● 83° horizontal field of view; 51.5° vertical field of view
● Auto framing (audio + face detect)
● Auto focus, brightness, and white balance
● Focus distance 1 m to infinity
