Проектор BenQ TH685, DLP, Full HD (1920x1080), 10 000:1, 3500 lm, HDMI, VGA, USB

BenQ TH685



Go Big. Stay Home.
Experience ultimate gaming. TH685 is supercharged with low input lag for real-time video game thrills. Stunning 1080p HDR graphics and 3500 lumens of ultra-brightness deliver intense action, even in daylight. And, awe-inspiring sound immerses you in epic gameplay like nothing you’ve seen before.



Ready to Get Real?
Be amazed by hyper-realistic HDR details on massive Full HD 1080p projected images that put big screen TVs to shame. Team up with TH685 and your favorite video game console to lead your team to victory on the battlefield and the game courts.









 Low Input Lag
Input lag is like bad lip-sync. It can turn a close game of NBA Live into a frustrating experience. Fortunately, TH685 has breakthrough 8ms response time for smooth gameplay in virtual real-time.









Exclusive Game Mode
Wins Every Time
TH685’s Game Mode fine-tunes images, enhancing dark scenes with greater clarity and precision. You’ll level up by spotting enemies and finding every hidden secret in RPGs.









Спецификации:



Main Specifications

Resolution

1080p (1920x1080)

Brightness (ANSI lumens)

3500lm

Contrast Ratio (FOFO)

10,000:1

Speaker

5W Chamber Speaker x 1

All Specifications

Display

Projection System

DLP

Resolution

1080p (1920x1080)

Resolution Support

VGA(640 x 480) to WUXGA(1920 x 1200)

Brightness (ANSI lumens)

3500lm

Contrast Ratio (FOFO)

10,000:1

Display Color

30 Bits (1.07 billion colors)

Native Aspect Ratio

16:9

Light Source

Lamp

Light Source Life

Normal 4,000 hours

Eco 10,000 hours

SmartEco 8,000 hours

LampSave 15,000 hours

Optical

Throw Ratio

1.13~1.46

100" @ 2.5m (100" @ 8.2ft)

Zoom Ratio

1.3x

Digital Lens Shift

Vertical ±5%

Keystone Adjustment

Auto 1D Vertical ±30 degrees

Projection Offset

105%

Clear Image Size (Diagonal)

60"~200"

Image Size

30"~300"

Horizontal Frequency

15K~102KHz

Vertical Scan Rate

23~120Hz


Picture Mode

Bright / Living Room / Cinema / Sports / Game / HDR10 / HLG / (3D)* / User 1 / User 2

Color Wheel Segment

6 segment (RGBWYC)

Color Wheel Speed

2X(2D/3D, 50Hz/60Hz) , 3D max 144Hz

Rec.709 Coverage

95%

Audio

Speaker

5W Chamber Speaker x 1

Interface

PC (D-Sub)

X1

Monitor Out (D-Sub)

X1

HDMI

X2 (HDCP2.2)

USB Type A

X1 (1.5A power)

Audio in (3.5mm Mini Jack)

X1

Audio out (3.5mm Mini Jack)

X1

RS232 (DB-9pin)

X1

IR Receiver

X2 (Front / Top)

Security Bar

Yes (Security Bar, Kensington Lock)

Special Feature

HDR

Yes (HDR10, HLG)

Input Lag (Under Fast Mode) 1 frame (8.33ms) 120Hz***

CinemaMaster Audio+2

Yes

LumiExpert

Yes

Compatibility

HDTV Compatibility

720p 50/60Hz, 1080i 50/60Hz, 1080p 24/25/30/50/60Hz, 2160p 23/24/25/30/60Hz

Environment

Power Supply

VAC 100 ~ 240 (50/60Hz)

Typical Power Consumption

Max 340W,  Normal 297W, Eco 206W

Standby Power Consumption

0.5W Max. at 100 ~ 240VAC

Acoustic Noise (Typ./Eco.)

35/29 dBA

Operating Temperature

0~40℃ (Celcius)

Dimension and Weight

Dimensions (W x H x D) (mm/inch)

312 x 110 x 225 mm (12 x 4 x 9 inch)

Net Weight (Kg/ lbs)

2.8 kg (6.2 lbs)
