Name: LED луна за вграждане Ledvance DL SLIM DN 155 WT, 12W, 240V, 1020lm, защита (IP20), 3000K
Brand: Ledvance
SKU: LDOWNLEDVANCE4058075079038
Price: 17.91 EUR
Availability: InStock

Описание Характеристики Ревюта / Въпроси Документация

Product benefits

Very slim housing
Low installation depth
High luminous efficacy
Energy savings up to 60 % (compared to luminaires that use CFL lamps)
Very homogenous light
Functional design
Easy installation with fast connection
Simple installation thanks to integrated driver

Areas of application

Direct replacement for luminaires with compact fluorescent lamps
General illumination
Public areas
Stairways
Corridors
Foyers
Shops

Product features

Small visible bezel
Connector box with push wire terminal for tool-free connection
Light guide made of non-yellowing PMMA for long lifetime

Safety advice

All electrical connections must be made by a qualified person.
Caution, risk of electric shock.
The luminaires are not suitable for covering with thermally insulated material.

Technical data

Electrical data

Nominal wattage	12.00 W
Nominal voltage	220…240 V
Mains frequency	50…60 Hz
Nominal current	71.7 mA
Inrush current	15.6 A
Inrush current time Th50	50 µs
Max. number of luminaires per miniature circuit breaker B16	48
Max. number of luminaires per miniature circuit breaker C10	38
Max. number of luminaires per miniature circuit breaker C16	61
Power factor λ	0.50
Total harmonic distortion	< 20 %
Protection class	II
Operating mode	Integrated LED driver

Photometrical data

Luminous flux	1020 lm
Luminous efficacy	85 lm/W
Color temperature	3000 K
Light color (designation)	Warm White
Color rendering index Ra	> 80
Standard deviation of color matching	< 6 sdcm
Luminous intensity	-
Flickering metric (Pst LM)	-
Stroboscope effect metric (SVM)	-
Photobiological safety group acc. to EN62778	RG0
Photobiological safety group acc. to EN62471	RG0
Beam angle	120 °

Dimensions & Weight

Diameter	169.00 mm
Height	30.00 mm
Product weight	272.00 g

Materials & Colors

Product color	White
Housing color	White
Body material	Polycarbonate (PC)
Cover material	Polycarbonate (PC)
Light emitting surface material	Polycarbonate (PC)
Glow Wire Test according to IEC 60695-2-12	650 °C
Mercury content	0.0 mg

Application & Mounting

Ambient temperature range	-20…+50 °C
Temperature range at storage	-30…+70 °C
Type of connection	Screwless terminal, 2-Pole
Type of protection	IP20
Protection class IK (shock resistance)	IK03
Dimmable	No
Mounting type	Recessed
Mounting location	Ceiling
Application environment	Indoor
Mounting diameter	155,0 mm
Mounting depth	50,0 mm
With light source	Yes
Replaceable light source	No

Lifespan

Lifespan L70/B50 at 25 °C	30000 h 1)
Lifespan L80/B10 at 25 °C	20000 h 1)
Lifespan L90/B10 at 25 °C	12000 h
Number of switching cycles	50000

1) t[h]: L70 / B50 @ 25 °C (Ta), t[h]: L80 / B10 @ 25 °C (Ta), t[h]: L90 / B10 @ 25 °C (Ta)

Control gear

Output current	180 mA
ECG - Output ripple current	< 6.5 %

Certificates & Standards

Standards	CE, CB, EAC
Luminaire with limited surface temperature, "D sign"	No
Ball shot safe	No
Replaceable light source (EPREL)	Not replaceable

Additional product data

Number of illuminants

Not relevant

PRODUCT SHEET RELATING TO ENVIRONMENTAL QUALITIES AND CHARACTERISTICS

Quantity of precious metals	Contains at least 10 mg
Quantity of rare earths	Contains at least 1 mg

Виж още LED Луни Ledvance
Виж всички LED Луни в категорията

Документация

Техническа спецификация

Технически характеристики

Тип:	Луна кръг
Влагозащитеност:	IP20 (Вътрешна употреба)
Мощност:	12 W
Напрежение:	240 V
Светлинен поток:	1020 lm
Цветна температура:	Топло бяла
Монтажен размер:	169x30mm
Особеност:	Няма
